Technical data
Technical Specification of the GORDON Roadster 1.6 T
Two-seat sports car with an engine in front and a rear-wheel drive.
- Engine:
- FM EP6 FADTX Euro VI
- Bedding
- longitudinal behind front axle
- Number of cylinders
- I4
- Lifting volume
- 1 598 ccm
- Drilling x lift
- 77,0 x 85,8 mm
- Compression ratio
- 10,2
- Maximum power
- 164 kW (223 HP)
- at
- 5 500 rpm
- Maximum torque moment
- 300 Nm
- at
- 2 250 rpm
- Valve gear
- DOHC
- Number of valves
- 16
- Fuel injection
- electronic Bosch MG1CS042
- Catalytic converter
- close-coupled TWC/GPF
- Engine block
- aluminium alloy
- Cylinder head
- aluminium alloy
- Cooling
- closed liquid-cooling system with an electric fan
- Alternator
- 14V - 90A
- Accumulator
- 12V- 60Ah
- Gearing system:
- Mazda MX 5
- Clutch
- single-disk clutch, dry, with a Bellewille spring
- Gearbox
- mechanic, five-speed, fully synchronized
- Gear ratios
- 1.st speed 3.136 : 1
- 2.st speed 1.888 : 1
- 3.st speed 1.330 : 1
- 4.st speed 1.000 : 1
- 5.st speed 0,814 : 1
- R 3.76 : 1
- Stable gear
- 4.10 : 1
- Drive
- rear-wheel
- Body / chassis:
- Body
- roadster - steel stamping, glass laminate, semi-monocoque frame welded from aluminium alloys, front and rear supporting frames
- Rear and front
- spring mountings
- telescopic springing and silencing units with a coiled spring
- Brakes
- hydraulic, two-circuit, with an under-pressure brake booster
- front brakes
- disk brakes with internal cooling
- rear breaks
- disk brakes with internal cooling
- Wheels
- steel, wired 5.5J x 15“
- Tires
- 185/70 R15 V
- Steering
- rack-and-pinion, power steering
- Steering wheel diameter
- 340 mm
- Sizes and weight:
- Length total
- 4035 mm
- Width total
- 1665 mm
- Height total
- 1230 mm
- Front / rear wheel track
- 1420 mm
- Axle base
- 2700 mm
- Trace rotation mean
- 11.8 m
- Ready weight
- 1 010 kg
- Maximum load
- 1 220 kg
- Fuel tank volume
- 85 l
- Performance:
- 0 – 100 km/h
- 5.1 sec.
- Top speed
- 210 km/hod
